Concentrically resize the polyline, so it represents the size of the slab you need by clicking on the polyline to select it, then Zoom in on a corner of the polyline.Next, select CAD> Boxes> Rectangular Polyline from the menu, then click and drag a polyline that snaps to the outside of the array of posts.

HOME DESIGN SOFTWARE FOR MAC THAILAND CONCRETE POST AND BEAM MAC

On a Windows PC, Preferences can be found by selecting Edit> Preferences from the menu and on a Mac selecting Chief Architect> Preferences from the menu. Open your program Preferences, and on the Behaviors panel, move the radio button to Concentric and set the Jump value, which is the distance you want between the outside of the posts and the edge of the structure's concrete slab, then click OK.Click OK to close the dialog and create the copies at the specified interval.You will see a value of -24' converts to -288". In this example, the posts are moved 24 feet down on-screen, or -24' on the Y Delta then press your Tab key on your key board. Check the box beside Move and specify the interval to move the copied posts.Check the box beside Copy and specify 1 copy.In the Transform/Replicate Object dialog: With the five posts selected, click the Transform/Replicate Object edit button again.Next, using the Select Objects tool, click and drag a rectangular marquee around all five posts to group-select them.

In this example, a total of five posts spaced 10 feet (On Center) apart are produced.

In this example, a Move interval of 120" along the X Delta is used. Check the box beside Move and specify the interval at which you would like the copied posts to be created.Check the box beside Copy and specify the number of copies you would like to make.Click on the post to select it, then click the Transform/Replicate Object edit tool.Do you want to turn on the display of this layer in the current view?". If you do not have the layer Framing, Posts turned on, you may see the message: "The layer "Framing, Posts" is not displayed.

Next, select Build> Framing> Post from the menu, and click in the drawing area to place a post.

Click OK to Make these changes and Done to close the Default Settings dialog.

On the Trusses panel, under the Member Depth heading, set the Top and Bottom chords and the Webbing to 5 ½".

Click OK to close the Post Defaults dialog and return to the Framing Defaults dialog.

On the Posts panel, click the Edit Post Defaults button and set both Width 1 and Width 2 to match the beam width of 5 ½".

Click OK to close the Floor Beam Defaults then set the Placement to Under Joists.In this example, 5 ½ inches( ") will be used for both. Under the General panel of the Floor Beam Defaults dialog, set the depth and width of the beam.Switch to the Beams panel and under Floor/Ceiling Beams click the Edit Floor Beam Defaults button.Select Framing from the list and click the Edit button.Select Edit> Default Settings from the menu.In this example, a simple structure composed of posts, beams, and trusses is created. There are a wide variety of post and beam construction styles, and a variety of different methods that can be used to model this type of structure in Chief Architect.
